  • Sequencer senses parachute deployment altitude.
  • Sequencer senses high altitude (any speed).
  • Headbox deployment unit operates when speed sufficiently reduced.
  • Sequencer restarts environmental sensing after delay.
  • Sequencer senses low speed and low altitude.
  • Start switches open to begin sequencer operation.
  • Leg restraint lines become taut and rivets shear, freeing lines from floor brackets.
  • Secondary cartridges fire as seat rises.
  • Bottom latches engage, top latches disengage seat rises up rails.
  • Thermal batteries activated, electronic sequencer powered up.
  • Electrical/crypto-erase connector disconnected.
  • Interseat sequencing system: Yes, via mode selector.
  • Aircrew services: Aircrew services package, interface for breathing gas, NBC ventilation supply, mic/tel and anti-g trousers Head equipment assembly services module Liquid suit connector assembly Auxiliary oxygen bottle.
  • f4 phantom canopy jettison actuator

  • Personal survival pack: Yes + automatic deployment and liferaft inflation.
  • Oxygen supply: Bottled emergency oxygen.
  • Leg restraints: Passive leg restraint system.
  • Seat adjustment: Up/down actuator operated 28 Vdc.
  • Electronic sequencer: Yes, powered by thermal batteries.
  • Automatic back-up unit: Yes, barostat controlled.
  • Drogue deployment: Cartridge initiated, electronic sequencer controlled.
  • f4 phantom canopy jettison actuator

    Parachute deployment: Cartridge initiated.Crew size range: Eurofighter-specific crew size range.Crew boarding mass range: 61.0 to 133.5 kg.Minimum height/Speed: Zero/zero in near level attitude.

    #F4 phantom canopy jettison actuator install#

    Looking to install a new seat into your aircraft? Let us help you find your perfect solution – check out our New Seat Installations & Retrofits page for more information. The Eurofighter is currently operational in the following countries: Austria, Germany, Italy, Saudi Arabia, Spain and the United Kingdom. Under certain speed and altitude conditions, the recovery timings at which the parachute is deployed are varied in order to optimise the terrain clearance. The Mk16A ejection seat utilises a second generation digital seat sequencer which incorporates a strategy of continuous sensing of external environmental parameters.

    #F4 phantom canopy jettison actuator series#

    Due to the capabilities and wide operating envelope of the aircraft, Martin-Baker was presented with a series of challenges which have had to be overcome during the development of the seat, such as the accommodation of a wider range of pilot models covering height and weight requirement, as well as achieving compatibility with equipment such as the Head Mounted Display (HMD), Chemical and Biological protection units (CB) and general aircrew equipment. The development of the Mk16A ejection seat for the Eurofighter Typhoon was carried out at Martin-Baker’s facilities at Denham, Chalgrove and Langford Lodge. MK16A Ejection Seat for Eurofighter Typhoon
